Here in Kansas and "Tornado Alley," we know a few things about spinning air.
Our HE Series Cyclones are designed for High Efficiency Particle Separation at it's finest.

Placeholder image

⚙Although there are no actual moving parts in the HE Series Cyclones from Midwest Custom Solutions, we remain steadfast in providing the same attention to detail and quality for each one that leaves our facilities as those products which are far more complex in design and operation.

⚙As with all of our products, we've designed and engineered our HE Series Cyclones with same strength, durability, efficiency and longevity you've come to expect from each and every product manufactured by MCS. We build your equipment as though it were being installed and used in our own facilities.

⚙With this lofty goal in mind, we’ve selected only the highest quality materials for our HE Series of Cyclones. Our highly skilled fabrication technicians have years of experience in their craft and know how to do things “the right way.” You can see their craftsmanship in each and every piece of equipment which leaves the MCS facilities.

⚙All frame and support structures are built for rugged, continuous, and thorough material processing. Structural framing and cross-supports are all thoughtfully and strategically engineered with ease of access, safety and durability in mind.

⚙Cyclone processing air rotation may be specified by client in a clockwise or counterclockwise direction. Inlet and outlet ducting will be manufactured to direct airflow as required to suit your unique operational needs.

⚙Access Panels for clean-out and interior inspection of expansion chambers come standard in all of the HE Cyclones from Midwest Custom Solutions. Mounting brackets and foot pads are meticulously installed by our technicians who know the importance of proper equipment installation on your site.

⚙All rounded components are precision rolled and continuously welded. Only high-quality fasteners are used in assembly to ensure durability, withstand vibration and provide longevity of use in the field.

⚙As with all of the products manufactured at Midwest Custom Solutions, our HE Series Cyclones are finely finished with high-quality, industry-leading paints, coatings and sealing products. We diligently strive to build value into every facet of our products, ensuring all of our equipment provides the longest-lasting, greatest value for your investment dollars.

Placeholder image
Placeholder image


Height . . . . . . . . . . . . . . . . . 136.25in. / 11.35ft.
Width . . . . . . . . . . . . . . . . . . . . 35.00in. / 2.92ft.
Length . . . . . . . . . . . . . . . . . . . 33.50in. / 2.79ft.
Inlet Cylinder Diameter . . . . . 21.00in. / 1.75ft.
Height to Mounting Pads . . . 95.25in. / 7.94ft.


Height . . . . . . . . . . . . . . . . . . . 346.08cm / 3.46m
Width . . . . . . . . . . . . . . . . . . . . . 88.90cm / 0.89m
Length . . . . . . . . . . . . . . . . . . . . 85.09cm / 0.85m
Inlet Cylinder Diameter . . . . . . 53.34cm / 0.53m
Height to Mounting Pads . . . 241.94cm / 2.42m

Placeholder image

Placeholder image
So, are you thinking: "Yeah, the HE-21 is close... but not quite what I'm looking for. What can you do to help me out?"

Feel free to reach-out to us using our Contact page and we will be happy to answer your questions or address your concerns.
We look forward to speaking with you!

Would you like to download the Midwest Custom Solutions' HE Series Cyclone Product Marketing Brochure?

Click/Tap the "GET PDF" button above to obtain a printable, transportable PDF version of our HE Series product information above.
