Moving large volumes of loose process material isn't as easy as it may appear.
If you have questions about it, you've come to the right place.

Tandem-rotating auger screws, massive hopper, ruggedized drive assembly...
the perfect solution to your processed material handling equation.

Placeholder image

⚙As with all the equipment Midwest Custom Solutions manufactures, our 4x9in. Auger Live Bottom Tank is constructed from high-quality materials and assembled by our highly skilled fabrication technicians. You will be able to see their craftsmanship in every piece of equipment that leaves the MCS facilities.

⚙Only industry-leading, serviceable bearings and drive assemblies are incorporated into our products. We know you expect to get the most from your equipment investment dollars and MCS strives to meet and exceed your high operational expectations daily.

⚙We've incorporated polycarbonate viewing windows into our hopper tank design to provide quick reference of volume and confirmation of material movement. Additionally, a convenient clean-out panel is provided to allow for inspection of critical areas of material flow.

⚙There are four 9in. augers assembled in a tandem-rotating configuration, mixing and pushing the combined material to the outlet just below the drive assembly. Auger selections are made from industry-leading suppliers constructed from the highest quality of materials.

⚙All components are mounted on a muscle-bound frame which provides a strong platform of operation for countless hours of trouble-free running in your most challenging work environments.

⚙Drive motor and gearbox selections are made from only industry-leading manufacturers to ensure durable, long-wearing operation. Drive sprockets and chains are designed and selected for their durability and longevity of use in the field.

⚙Your organization's focus on technician/employee safety is Midwest Custom Solutions' number one priority, and we've designed ALL of our products with the appropriate safety guards on every drive system, each auger screw and all pinch hazards.

⚙As with all of the products manufactured by Midwest Custom Solutions, our XB-4.9 Live Bottoms are finely finished with high-quality, industry-leading paints, coatings and sealing products. We diligently strive to build value into every facet of our products, ensuring all of our equipment provides the longest-lasting, greatest value for your investment dollars.

Placeholder image
Placeholder image

US / STANDARD

Height . . . . . . . . . . . . . . . . . . 139.19in. / 11.60ft.
Width . . . . . . . . . . . . . . . . . . . . . 71.13in. / 5.92ft.
Length . . . . . . . . . . . . . . . . . . 176.69in. / 14.72ft.
Outlet Discharge Height . . . . . 17.69in. / 1.47ft.
Hopper Height . . . . . . . . . . . . . . . 108in. / 9.00ft.



METRIC

Height . . . . . . . . . . . . . . . . . . . 353.54cm / 3.54m
Width . . . . . . . . . . . . . . . . . . . . 180.67cm / 1.81m
Length . . . . . . . . . . . . . . . . . . . 448.79cm / 4.49m
Outlet Discharge Height . . . . . . 44.93cm / .45m
Hopper Height . . . . . . . . . . . . 274.32cm / 2.74m


So, you like what you're seeing, but our XB-4.9 Live Bottom isn't quite what you're looking for? Let's talk about it.

Feel free to reach-out to us using our Contact page and we will be happy to answer your questions or address your concerns.
We look forward to speaking with you!
